Parts List
NO. QT Y. DESCRIPTION
1 1 Top Door
2 1 Bottom Door
3 4 Handle
4 1 Antenna
5 1 Controller
6 4 Rack
7 1 Water Bowl
8 1 Water Bowl Rack
9 1 Fan Tube
10 1 Lower Fan Tube Assembly
11 1 Body
12 1 Rear Leg Brace
NO. QT Y.
DESCRIPTION
13 1 Heat Deflector Tent
14 1 Grease Tray
15 1 Charcoal Basket and Partition
16 1 Ash Tray
17 1 Right Legs
18 1 Left Legs
19 1 Front Leg Brace
20 10 Rack Support
21 2 Locking Casters
22 2 Non Locking Casters
23 1 Meat Probe
1 Power Cord (not pictured)
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT Customer Service at www.masterbuilt.com/pages/support. Please have
the model number and serial number available. These numbers are located on the silver rating
label on the smoker.
STOP
• BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• Assemble on a clean flat surface.
• Recommend assembling on cardboard to avoid oil residue on floors or scratches.
• Gloves recommended for assembly.
• Tools needed: Phillips head screwdriver, adjustable wrench, 19mm socket wrench.
• Approximate assembly time: 45 minutes.
• Recommend two people assemble to increase ease and reduce assembly time.
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.
• Remove all printed labels from the smoker before use.
6
