Wiring Diagram
Smoke adjustment
setting hole
Power cord
White
Black
Controller
Fiberglass wiring
Temperature sensor
Fuse for element on
back of controller
WhiteRed
WhitePurple
White
Orange
Connector
Element
Auger drive motor
Intake fan
Crucible
