model no. 5742 | contact us 1-800-689-9928
LED WORKLIGHTS
(fig 6)
The LED worklights, located on both sides of the
cordless impact driver, will illuminate when the
variable-speed trigger switch is depressed, and
will automatically turn off a short while after the
variable-speed trigger switch is released. This
provides additional light on the surface of the
workpiece for operation in lower light situations.
MAGNET STORAGE ON TOP
(fig 7)
The magnet on the top of the impact driver allows
for convenient short-term storage of screws and
bits.
OPERATING INSTRUCTIONS
NOTICE: When the tool is overheating, the LED worklight will quickly flash to alert you to turn off the tool to allow it
to cool.
fig 7
Magnet
Bit
fig 6
LED worklights
