model no. 054-8153-0 | contact us 1.800.689.9928
8
PACKAGE CONTENTS
Reciprocating saw, hex key, general cutting blade and instruction manual
KEY PARTS DIAGRAM
1 5234
6 7
No. Part No. Part
1 Variable-speed trigger switch 5 Handle
2 Blade-clamp lever 6 Tool-less blade clamp
3 Pivot shoe 7 Shoe-adjustment screw
4 Blade
• Thelabelonyourtoolmayincludethefollowingsymbols.Thesymbolsandtheirdefinitionsare
asfollows:
V ..................... Volts
A ..................... Amperes
Hz ................... Hertz
W .................... Watts
min ................. Minutes
............... Alternating current
............. Direct current
n
0
................... No load speed
............... Class II Construction
…/min ........... Revolutions or reciprocation per minute
............... Grounding terminal
BPM ............... Beats per minute
.............. WARNING – To reduce the risk of injury, user must read instruction manual.
WARNING!
• Remove the reciprocating saw from the package and examine it carefully. Do not discard
the carton or any packaging material until all parts have been examined.
FPO
KEY PARTS DIAGRAM
SAFETY GUIDELINES
