No. Part No. Description No. Part No. Description
1 5620398000 Flange Bolt 34 5700048000 Ball Bearing
2 3550222000 Clamp 35 5610048000 Tapping Screw
3 3810397000 Blade 36 3700255000 Washer
4 3550225000 Inner Flange 37 5650007000 Spring Washer
5 5620039000 Screw 38 3121054000 Spring
6 5660030000 Circlips For Shaft 39 5650005000 Plain Washer
7 3127547000 Moving Guard Lever 40 5610013000 Tapping Screw
8 3420334000 Lower Guard 41 3126069000 Transparent Cap
9 3700586000 Bushing 42 4890776000 PCB Assembly
10 3660170000 Torsion Spring 43 2740125000 Stator
11 5610094000 Thread Forming Screw 44 4930013000 Receptacle
12 3420311000 Gear Case Cover 45 3127546000 Motor Housing
13 5700019000 Ball Bearing 46 3321208000 Front Handle
14 3551045000 Gear Shaft 47 5610044000 Tapping Screw
15 3700281000 Wave Washer 48 4960021000 Carbon Brush Assembly
16 5660023000 Circlips For Hole 49 2800006000 Brush Holder Assembly
17 5680160000 Plain Key 50 3700539000 Epoxy Board
18 3551043000 Gear 51 5610029000 Tapping Screw
19 3550240000 Lock Ring 52 3127545000 Rear Cover
20 5610058000 Thread Forming Screw 53 5610042000 Tapping Screw
21 3121051000 Stopper 54 5640151000 Bolt
22 3421565000 Upper Guard 55 5650017000 Plain Washer
23 5700041000 Oil Impreging Bearing 56 3400174000 Lock Rod
24 3421261000 Gear Case 57 3127548000 Depth Adjusting Lever
25 3660072000 Spring 58 5630217000 Square Nut
26 5660010000 E Ring 59 3660036000 Spring
27 3402701000 Spindle Lock Assembly 60 3400011000 Wing Bolt
28 5610064000 Thread Forming Screw 61 5620042000 Screw
29 3126277000 Fan Baffle 62 5630001000 Hexagon Nut
30 3121057000 Rubber Ring 63 5670263000 Spring Pin
31 5700015000 Ball Bearing 64 3704587000 Bevel Support
32 2750888000 Rotor 65 3705686000 Base Plate
33 3120563000 Dust Seal 66 3704591000 Depth Bracket
No. Part No. Description No. Part No. Description
67 5680009000 Rivet 75 4870530000 Trigger Switch
68 3704593000 Support 76 3700367000 Cord Anchorge
69 3321801000 Right Handle 77 5610093000 Tapping Screw
70 4890462000 PCB Assembly 78 4930004000 Connector
71 4930012000 Terminal 79 3321800000 Left Handle
72 3700540000 Sponge 80 3121050000 Cord Guard
73 2823869000 Internal Wire Assembly 81 4810002000 Power Cord & Plug
74 2823868000 Internal Wire Assembly
If any parts are missing or damaged, or if you have any questions, please call the Toll-free Helpline,
at 1-800-689-9928.
PART LIST
