OPERATING INSTRUCTIONS
15
AIR-POWERED 3-IN-1 NAILER 058-8489-4
Loading fasteners
1. Disconnect the tool (1) from the air
supply (2)
(fig A)
.
2. Hold the tool firmly with one hand and
use the other hand to press the latch (1)
on the magazine (2) and slide it back
(fig B)
.
DANGER!
Potential hazard that will result in serious injury or loss of life.
• Disconnect the tool from the air supply before loading or changing
fasteners.
• Do not point the tool towards the operator or other people while loading or
changing fasteners.
• Do not hold the tool with the trigger pressed while loading or changing
fasteners. Failure to comply will lead to serious injury or loss of life.
MC-588489-02
fig A
1
2
MC-588489-03
fig B
1
2
