MasterCraft 058-8489-4 User Manual

PARTS LIST
27
AIR-POWERED 3-IN-1 NAILER 058-8489-4
No. Description Qty. No. Description Qty.
1 Bolt M5 X 16 1 27 Adjustment washer 1
2 Air cover 1 28 Compressed spring 1
3 Exhaust vent 1 29 Pusher stem 1
4 Bolt M5 X 25 4 30 Adjustment stand 1
5 Spring washer 5 4 31 Pin A1.5 x 8 2
6 Cylinder cover 1 32 Steel ball (Dw=2.5) 2
7 Flat washer 1 33 Compressed spring B 2
8 O-ring 18 X 1.8 1 34 Adjustment nut II 1
9 Compressed spring 1 35 Snap retainer 2 1
10 O-ring 48.7 X 2.65 1 36 Regulating stem 1
11 O-ring 38 X 3.5 1 37 Adjustment bolt 1
12 O-ring 25 X 3.5 1 38 Bolt M4 X 8 2
13 Switch valve 1 39 Safety stand cover 2
14 O-ring 60 X 2.5 1 40 Safety stand 1
15 Collar 1 41 Safety tip 1
16 O-ring 42 X 2.5 1 42 O-ring 711.7 X 2.4 1
17 O-ring 42 X 3.55 2 43 O-ring 13 X 1.5 1
18 Cylinder 1 44 Valve seat 1
19 O-ring 31 X 3.55 1 45 O-ring 3.75 X 1.8 2
20 Drive blade 1 46 O-ring 6 X 2 1
21 Bumper 1 47 O-ring 7.2 X 1.9 1
22 Washer 1 48 Valve guide 1
23 Gun body 1 49 Compressed spring 1
24 Bumper 1 50 O-ring 2.5 X 1.5 2
25 Pin 3 x 26 2 51 Trigger pin 1
26 Safety Stand 1 52 O-ring 15.2.65 1
