MasterCraft 058-8489-4 User Manual

PARTS LIST
28
AIR-POWERED 3-IN-1 NAILER 058-8489-4
If any parts are missing or damaged, or if you have any questions, please call 1-800-689-9928.
53 Trigger seat 1 75 Compressed spring 1
54 Compressed spring 1 76 Fixed lever 1
55 Pin sleeve 3 77 Bolt M4 X 20 3
56 O-ring 1 78 Fixed magazine 1
57 Pin 1 79 Nail guide strip 1
58 Switch handle 1 80 Joint strip 1
59 Movable plate 1 81 Bolt M4 X 8 4
60 Fixed plate 1 82 Bolt M4 X 6 2
61 Bolt M4 X 15 2 83 Fixed seat 1
62 Pin 1 x 10 2 84 Spring washer 4 1
63 Pin 2 85 Pin (3 x 18) 1
64 Pin (2 x 6) 2 86 Safety plate 1
65 Compressed spring 1 87 Trigger 1
66 Spring strip 1 88 Trigger pin 1
67 Drive guide 1 89 Washer 4 1
68 Pin (3 x 38) 1 90 Self-lock bolt M4 1
69 Pusher 1 91 Pin 4 x 6 1
70 Pusher pipe 3 92 Rubber handle case 1
71 Movable magazine 1 93 End cap 1
72 Compressed spring 3 94 Air inlet plug 1
73 Bolt 2 95 Air inlet plug bush 1
74 Fixed seat 1
No. Description Qty. No. Description Qty.
