11
OPERATING INSTRUCTIONS
WARNING:
When tightening the waterproof nut, the inner O-ring should be present and must be
tightened, otherwise the battery pack will short circuit and the protection function will start,
then the pump will not operate normally.
Charging
Battery level
Dysfunction
3 Lights flashing
1 light—30%
2 lights—60%
3 lights—100%
1 LED flashes
2 LEDs flash
3 LEDs flash
Model LED Action
Pump running dry. Turn off pump. Relocate intake
filter to deeper water.
While charging, lights will flash then turn to solid
one by one as the power level reaches 30%, 60%
and 100%.
Overload. Turn off the pump. Inspect the impeller to
ensure there is not an obstruction causing the issue.
Battery fault. Turn off the pump and send the pump
to store for service.
CHARGING
1. Set the ON / OFF switch (A) to the OFF position.
2. Unscrew the waterproof nut (D) and do not loosen the O-ring (C) on the waterproof nut.
3. Insert the charging connector (B) into the charging port.
4. Plug the charger (E) to an AC power source (F).
5. After charging, remove the charging connector (B) from the pump and unplug the charger from
the power supply.
6. Tighten the waterproof nut (D).
A
B
E
F
D
C
To Next Page
