model no. 062-3406-0 | contact us 1-800-689-9928
4
Model number 062-3406-0
Voltage 18 V
Battery Ah 5 Ah
Max. head 30' (9.1 m)
Max. flow 1452 U.S. GPH (4596 L/h)
Discharge size 1" (2.5 cm)
Charging cable length 6' (1.8 m)
HP 1/6 HP
Power 10 A
TECHNICAL SPECIFICATIONS
Charging time
Operating time
Battery cycle
1 hr 50 minutes
>25 min
>300 cycles (battery capacity>70%)
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
5' (1.5 m)
10' (3 m) 15' (4.5 m) 20' (6 m)
1163 U.S GPH
(4402 L/h)
925 U.S GPH
(3502 L/h)
635 U.S GPH
(2404 L/h)
450 U.S GPH
(1703 L/h)
PERFORMANCE
For best performance, the maximum recommended hose length is 100' (30 m). The pumping
capacity or water flow rate of any pump depends on several factors. The larger the inside
diameter and the shorter the length of hose, the less pressure that is lost (or the larger the flow
rate). If the hose runs uphill or is extra-long, it is recommended you use a large diameter of pipe.
