MasterCraft 062-3413-2 - Key Parts Diagram; Parts List

model no. 062-3413-2 | contact us 1-800-689-9928
KEY PARTS DIAGRAM
KEY PARTS DIAGRAM
PART LIST
No. Description
Bolt M8*4
Spring washer 8
Washer 8
Pump support
Bracket for pump support
Column tie bolt M6*12
Priming plug
O-ring 8.2*1.9
Pump casing
O-ring 26.3*2.2
Venturi tube
Diffuser
Hex nut 10
Spring washer 10
Washer 10
Impeller
Mechanical seal
O-ring 163*3.55
Seal holder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Quantity
2
2
2
1
2
8
2
2
1
1
1
1
1
1
1
1
1
1
1
No. Description
Pump support
Terminal box
Power switch
Sealing ring for terminal
Cover
Capacitor 40Mf/250V
Bolt M4*8
Cord clip
Power cord
Cable holder
Ball bearing 6202-Zz/Z2
Shaft key A4*10
Rotor
Motor stator
End plate
Bolt M5*138
Fan
Fan cover
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Quantity
1
1
1
1
2
1
2
1
1
1
2
1
1
1
1
4
1
1
12
11
21
22
23
24
25
26
27
28
29
30
31
32
30
33
34
35
36
37
1
2
3
4
5
6
7
8
10
12
13
9
14
15
16
17
18
19
20
