model no. 062-3503-8 | contact us 1-800-689-9928
12
ASSEMBLY INSTRUCTIONS
APPLICATION
• The battery back-up sump pump is not a substitute for your primary sump pump. It is
designed to temporarily back up your primary sump pump when the main sump pump
fails or during a power outage.
• This unit is not designed as a waterfall or fountain pump, or for applications involving salt
water or brine. Use with waterfalls, fountains, salt water or brine will void warranty.
• Do not use where water recirculates.
• Not designed for use as a swimming pool drainer.
Flathead screwdriver
Threaded adaptor
(pipe to pump)
1 1/4" (3.2 cm) or
1 1/2" (3.8 cm)
check valve
1 1/4" (3.2 cm) or
1 1/2" (3.8 cm)
“Y” pipe
1 1/4" (3.2 cm) or
1 1/2" (3.8 cm)
ABS or PVC pipe
Hacksaw Cable ties Safety goggles Tape measure
Cross-head
screwdriver
Channel lock pliers Pipe wrench
ABS or PVC cement
(to match the pipe)
Flexible plastic
pipe/clamps
Thread tape
1 1/4" (3.2 cm) or
1 1/2" (3.8 cm)
90° elbow
TOOLS REQUIRED
MATERIALS REQUIRED (NOT INCLUDED)
