model no. 062-3503-8 | contact us 1-800-689-9928
4
QUICK START GUIDE
Wrap the thread of the discharge
of the backup pump with non-stick
tape.
Thread a 90°,1 1/4" (3.2 cm) FPT
elbow onto the discharge of the
backup pump.
Wrap the thread of the check valve
with non-stick tape and thread the
check valve onto the 90° elbow.
2
Try to assemble the backup pump
(no glue). Connect the check valve
of backup pump with rubber hose.
Connect the upper end of the tee to
the discharge plumbing. Recheck the
alignment and glue the joints.
After the glue has set, slide the hose
clamps onto the rubber hose and
tighten the clamps.
3
Try to assemble the primary (no glue). Wrap
the thread of the check valve with non-stick
tape and thread the check valve to the
pump outlet. Then connect the check valve
and the tee with rubber hose.
1
