23
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the belt sander.
Any attempt to repair or replace electrical parts on this belt sander may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
12-1320-626-03-S
Bearing
1
2
17-0116-202-02-6
Stator
1
3
17-0116-205-02-6
Rotor
1
4
12-1320-606-00-S
Bearing
1
5
12-0700-210-00-6
Pin
1
6
20-0115-008-16-6
Sleeve
1
7
20-0115-009-00-6
Drive pulley
1
8
16-5071-391-FL-6
Power cord
1
9
21-0116-002-00-6
Small gear
1
10
12-1320-608-03-S
Bearing
1
11
20-0115-005-12-6
Bearing cover
1
12
12-0603-010-16-6
Screw
3
13
20-0115-010-00-6
Gear shaft
1
14
20-0101-008-00-6
Pin
1
15
20-0115-011-00-6
Big gear
1
16
12-0830-100-16-6
Washer
1
17
12-1010-100-16-6
Washer
1
18
12-1320-627-00-S
Bearing
1
19
13-1000-101-16-6
Brush support
2
20
24-0116-001-06-8
Sanding belt
1
21
21-0116-003-00-7
Belt cover
1
22
24-0116-018-1X-6
Belt
1
23
18-0101-019-01-7
Cord protector
1
24
12-0310-06M-12-6
Nut
1
25
21-0116-005-00-6
Driven pulley
1
26
12-0810-060-16-6
Washer
1
28
21-0116-006-00-6
Bearing support assembly
1
29
12-1310-810-00-C
Needle bearing
2
30
12-1000-120-16-6
“C” clip
2
32
12-0622-912-16-6
Screw
4
33
30-0116-400-00-6
Rear wheel
1
34
12-0622-912-16-6
Screw
1
37
14-0116-074-1N-6
Carbon brush
2
38
18-0116-001-47-6
Left housing
1
PARTS LIST
!
