PARTS LIST
No Description QTY No Description QTY
1 CYLINDER HEAD SUBASSEMBLY 1 64 FUEL TANK COVER, 1
2 CYLINDER HEAD GASKET, 1 65 FUEL VALVE ASSY 1
3 CYLINDER HEAD COVER SUBASSEMBLY 1 66 COLLAR 2
4 CYLINDER HEAD COVER GASKET, 1 67 WASHER 4
5 BREATHER TUBE, 1 68 BOLT 4
6
BOLT（M6×12)
4 69 OIL LEVELER ASSY 1
7
STUD（M6×96)
2 70 SCREW 2
8
STUD（M8×34）
2 71 FUEL TUBE 1
9 PIN (φ10×14) 2 72 FLYWHEEL NUT 1
10 CYLINDER HEAD BOLT 4 73 STARTER PULLEY 1
11 SPARK PLUG 1 74 IMPELLER 1
12 HIGH TENSION LINE BLOCK, 1 75 FLYWHEEL SUBASSEMBLY 1
13 OIL SEAL 2 76 BOLT 2
14 DRAIN PLUG BOLT 1 77 IGNITION COIL 1
15 WASHER 1 78 BOLT 2
16 CRANKCASE SUBASSEMBLY 1 79 GOVERNOR SPRING 1
17 BEARING 1 80 GOVERNOR SUPPORT SUBASSEMBLY 1
18 PIN 2 81 NUT 1
19 CRANKCASE GASKET 1 82 PIN 1
20 BEARING 1 83 SPLIT 1
21 OIL DIPSTICK SUBASSEMBLY 1 84 GOVERNOR ARM 1
22 BOLT 6 85 THROTTLE VALVE RETURNING SPRING 1
23 CRANKCASE COVER 1 86 GOVERNOR ROD 1
24 CRANKSHAFT ASSY. 1 87 GOVERNOR GEAR ASSY 1
25 PISTON 1 88 THROTTLE CONTROL ASSY 1
26 PISTON PIN 1 89 ENGINE FRAME ASSY 1
27 PISTON PIN CLIP 2 90 ENGINE FRAME CUSHION 1
28 CONNECTING ROD 1 91 ENGINE FRAME RIGHT CUSHION 1
29 THE FIRST RING 1 92 NUT 8
30 THE SECOND RING 1 93 BOLT 4
31 OIL RING SET 1 94 ENGINE FRAME SHOCK ABSORPTION SEAT 4
32 CAMSHAFT ASSY. 1 95 ENGINE FRAME LEFT CUSHION 1
33 EXHAUST VALVE 1 96 ENGINE FRAME CUSHION 1
34 INTAKE VALVE 1 97 BOLT 2
35 VALVE SPRING SEAT 2 98 ENGINE FIXED BOTTOM PLATE 1
36 VALVE TAPPET 2 99 CONTROL PANEL SUBASSEMBLY 1
37 VALVE LIFTER 2 100 BOLT 4
38 LIFTER STOPPER PLATE SUBASSEMBLY 1 101 CONTROL PANEL 1
39 VALVE ADJUSTING BOLT 2 102 GROUNDING TERMINAL SUBASSEMBLY 1
