MasterCraft 55-0343-4

TABLE OF CONTENTS
SPECIFICATIONS ………………………………………………………………………….…………………2
SAFETY INSTRUCTIONS………………………………………………………………….………………3-6
KNOW YOUR GENERATOR………………………………………………………………………………..7
PREPARING THE GENERATOR FOR USE………………………………………………………….. 8-10
SUBSEQUENT USE OF THE GENERATOR…………………………………………………… ……….10
OPERATION…………………………………………………………………………………………………..11
USING THE GENERATOR……………………………………………………………………………….12-14
AC USAGE……………………………………………………………………………………………13-14
STOPPING THE GENERATOR ……………………………………………………………………………. 16
MAINTENANCE ……………………………………………..…………………………………………... 16-19
STORAGE & TRANSPORTINGYOUR GENERATOR….………………………………………….……. 19
TROUBLESHOOTING ……………………………………………………………………………………… 20
COLD WEATHER STARTING TIPS …………………………………………………………………….…21
EXPLODED DRAWING……………………………………………………………………………………...22
PARTS LIST ………………………………………………………………………..…………………….….. 24
ORDERING REPLACEMENT PARTS……………………………………………………………………..25
LIMITED WARRANTY……………………………………………………………………………………...25
SPECIFICATIONS
Model 55-0343-4
Degree of Protection IP23
AC Output Voltage(V) 120V
Cont. AC Output(w) 1050
60Hz
Max. AC Output(w) 1350
Alternator
Power Factor 1.0
Model R100
Type 4-stroke, OHV air-cooled gasoline engine
Displacement(cc) 99cc
Lubrication Oil SAE 10W30
Lubrication Oil Volume(L) 0.35
Intake Valve 0.15mm
Engine
Exhaust Valve 0.20mm
Fuel 90 Octane Gasoline
Fuel Tank Capacity(L) 7.5
Sound Power Level (dB) 75dBA
Starting System Recoil
Unit
Dimensions and Weight
18 1/8 x 14 1/8 x 16 1/2" (46 x 36 x 42 cm), 57 lb 5 oz (26 kg)
Run Time (under 50% load) 9H
2
