40 VALVE ROCKER 2 103 POWER SUPPLY SOCKET SUBASSEMBLY 1
41 VALVE ADJUSTING NUT 2 104 SWITCH SUBASSEMBLY 1
42 VALVE ADJUSTING BOLT 2 105 OVERCURRENT PROTECTOR 1
43 VALVE SPRING 2 106 PANEL REAR CASE 1
44 BOLT 3 107 WASHER 2
45 RECOIL STARTER ASSY 1 108 WASHER 2
46 SHROUD 1 109 SCREW 2
47 BOLT 4 110 MOTOR ASSY. 1
48 CYLINDER BODY SHROUD 1 111 MOTOR BRACKET 1
49 BOLT 1 112 BOLT 4
50 CRANKCASE AIR DEFLECTOR 1 113 WASHER 1
51 BOLT 1 114 BOLT 1
52 SHROUD SHIELD 1 115 VOLTAGE REGULATOR 1
53 CARBURETOR GASKET 2 116 BOLT 2
54 CARBURETOR INSULATOR PLATE, 1 117 CARBON BRUSH SUBASSEMBLY 1
55 AIR CLEANER GASKET 1 118 BOLT 1
56 CARBURETOR ASSY. 1 119 MOTOR TAIL COVER, 1
57 AIR CLEANER 1 120 BOLT 2
58 NUT 2 121 BAND 1
59 MUFFLER ASSY. 1 122 BOLT 1
60 NUT 2 123 BOLT 1
61 EXHAUST OUTLET GASKET 1 124 MOTOR FRONT END COVER 1
62 FUEL TANK 1 125 BOLT 4
63 FUEL STRAINER 1
ORDERING REPLACEMENT PARTS
Customer service toll-free number for ordering parts: 1-800-689-9928
When ordering parts, please be prepared to give the following information:
•The product number: 55-0343-4
•The name of the product: MASTERCRAFT 1000W Gasoline Powered Generator
LIMITED WARRANTY
This MASTERCRAFT product is guaranteed for 2 years from the date of original retail purchase
against defects in materials and workmanship.
Subject to the conditions and limitations described below, this product, if returned to us with proof of
purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear the
cost of any repair or replacement and any costs of labour relating thereto.
These warranties are subject to the following conditions and limitations:
25
