PARTS LIST
48
MIG 140 INVERTER WELDER 058-9305-6
No. Description Qty. No. Description Qty.
1 Case cover 1
20 Tip 1
2 Handle 1
21 Ground cable and clamp 1
3 Hinge 2
22 MIG torch 1
4 Control board 1
23 MIG torch connector 1
5 Support board 1
24 MIG torch receptacle 1
6 Splint wire 1
25 Wire feeder 1
7 Center frame 1
26 Welding mode selector switch 1
8 Door 1
27 2T/4T Power switch, ON/OFF 3
9 Door latch 1
28 Potentiometer knob 2
10 Wire spool seat 1 29 Trigger switch 1
11 Wire spool bolt 1 30 Quick connector 2
12 Spool spring 1 31 Base pads 4
13 Wire spool cover 1 32 Case base 1
14 Wire spool adjust nut 1 33 Main PC board 1
15 Insulated connector 2 34 Fan 1
16 Front panel 1 35 Back panel 1
17 Front panel control board 1 36 Power cord 1
18 Front panel support 1 37 Main switch 1
19 Nozzle 1 38 Gas solenoid valve 1
