MasterCraft MIG 140 User Manual

TECHNICAL SPECIFICATIONS
3
MIG 140 INVERTER WELDER 058-9305-6
WELDER SPECIFICATION
POWER SUPPLY Single phase, 120 V, 60 Hz
MIG WELDING CURRENT 30–140 A DC
RATED INPUT CURRENT 20 A
RATED INPUT CAPACITANCE 2.4 KVA
NO-LOAD VOLTAGE 69 V
RATED WORKING VOLTAGE 18.5 V
RATED DUTY CYCLE 30%
EFFICIENCY 85%
POWER FACTOR 0.75
INSULATION CLASS H
ENCLOSURE PROTECTION IP 21 S
COOLING TYPE FAN COOLED
WIRE USED
0.023-0.035"
(0.58 - 0.89 mm) MIG wire
0.030-0.035"
(0.76 - 0.89 mm) flux-core wire
WIRE DIAMETER
0.023"
(0.58 mm) , 0.030" (0.76 mm) ,
0.035"
(0.89 mm)
ELECTRODE DIAMETER 1/16" (1.58 mm) , 5/64" (1.98 mm)
DIMENSIONS (L x W x H)
21 39/64 x 12 39/64 x 17 19/64"
(55 x 32 x 44 cm)
WEIGHT 39 lb 8 oz
(17.93 kg)
