QUICK START GUIDE
MIG/FLUX-CORE WIRE FEED WELDER KIT 058-8195-2
STEP 1
Installing the wire
Remove the nozzle (1) and contact tip (2) from
the end of the torch assembly. Identify the
leading end of the wire secured on the edge of
the wire spool. Place the spool on the hub with
the wire passing from the bottom of spool into
the drive mechanism.
pages 16-17, steps 1-4
STEP 2
Setting the wire tension
Press the trigger on the gun. Turn the drive
tension adjustment knob (1) clockwise, and
increase the drive tension until the wire seems
to feed smoothly without slipping.
page 18, steps 1-2
MC-588195-06
1
2
MC-588195-24
1
