PARTS LIST
33
MIG/FLUX-CORE WIRE FEED WELDER KIT 058-8195-2
If any parts are missing or damaged, or if you have any questions, please call 1-800-689-9928.
No. Description Qty. No. Description Qty.
1 Ground cable and clamp 1 20 Cable holder 1
2 Wire feed setting knob 1 21 Back panel 1
3 Torch cable holder 1 22 Gas hose connector 1
4 Cable holder 1 23 Rectifier 1
5 Front panel 1 24 Rectifier bracket 1
6 PCB support 1 25 Vertical middle panel 1
7 PCB 1 26 Spool holder 1
8 Bottom 1 27 Plastic hinge 2
9 Feet 1 28 Left panel 1
10 Control transformer 4 29 Fuse 1
11 Thermal relay 1 30 Red terminal 1
12 Circuit breaker 1 31 Black terminal 1
13 Main transformer 1 32 Door bolt 1
14 Fan bracket 1 33 Wire feeder 1
15 Fan 2 34 MIN/MAX 1/2 voltage switch 2
16 Fan blade 1 35 ON/OFF switch 1
17 Handle 1 36 Overload indicator 1
18 Right panel 1 37 MIG torch 1
19 Power cord 1
