TECHNICAL SPECIFICATIONS
3
MIG/FLUX-CORE WIRE FEED WELDER KIT 058-8195-2
POWER SUPPLY single-phase, 120 V, 60 Hz
NO-LOAD VOLTAGE 30V
OUTPUT CURRENT 35-80 A (Peak 130 A)
DUTY CYCLE 20% @ 80 A
WIRE USED MIG and flux-core wire
WIRE DIAMETER 0.023", 0.030", 0.035"
DIMENSIONS (L x W x H) 17.6" x 9.4" x 14.5"
WEIGHT 62 lb 10 oz
(28.42 kg)
Welding mode Materials For metal thickness Use wire size
Flux core Steel
20-gauge-5/32"
0.03" (1/32") 0.8 mm
0.035" (5/128") 0.9 mm
5/128-5/32"
1.0-4.0 mm
MIG Steel, Stainless steel
20-gauge-1/8"
0.03" (1/32") 0.8 mm
0.023" (3/128") 0.6 mm
5/128-1/8"
1.0-3.0 mm
