OPERATING INSTRUCTIONS
27
MIG/FLUX-CORE WIRE FEED WELDER KIT 058-8195-2
Instructions to be followed for the spot welding methods:
1. Select the wire diameter and heat setting recommended above for the intended method of
spot welding.
2. Tune in the wire speed as if a continuous weld is to be performed.
3. Hold the nozzle piece completely perpendicular to and about ¼ inch off the workpiece.
4. Pull the trigger on the torch and release it when the desired penetration is achieved.
5. Make practice spot welds on scrap metal and vary the duration of time of holding the trigger
until a desired spot weld is made.
6. Make spot welds on the actual workpiece at desired locations.
