Raising and Lowering the NXT Tower
The NXT tower is an upright, fixed tower. It can be lowered by remov-
ing two hand knobs on either side of the tower.
Depending upon the total aggregate weight of the tower and any
installed accessories, it is advisable to have a second person assist
in steadying the tower during the raising and lowering process on
the NXT tower.
Raising and Lowering the ProStar Tower
Lowering (And Leaving The Tower Attached):
• While applying some upward/forward pressure on the tower
header, loosen one of the hand knobs.
• Repeat for the other side (or a second person can do this simul-
taneously). NOTE: Typically, it is easier to loosen both sides first
compared to completely removing one knob and then loosening
and removing the second. The angled threaded can put the tow-
er/threads in a bind.
• Completely unscrew the hand knobs until they are disengaged (a
spring pushes them out).
• Fold tower back and rest on motor box (or other padding to pro-
tect upholstery).
If Removing, Follow These Additional Steps:
• Pull excess wires out from under the deck.
• Disconnect the light wires.
NOTE: On the tower side, fold the wires up and push up in the tower
tube. On the deck side, fold/loop the wires up and stuff back in the
access hole.
Do not plug the wires together. This will act as a direct short if the
light switch is turned on, resulting in a tripped circuit breaker or a
blown fuse.
The male connector should be inserted in the groove in the plastic
below the deck mount. Groove will be on the forward side of the hole.
