MasterCraft X23 User Manual

2016 OWNERS MANUAL / 067
FEATURES
01. Bow Ladder Lid
02. Ladder (where equipped)
03. Horn
04. Bow cleat
05. Ballast tank (beneath floorboard)
06. Holding tank pump-out
07. Freshwater tank fill
08. Instrument panel (details in Video Display Gauge
section)
09. Adjustable mirror
10. Navigation light
11. Steering wheel
12. Midship cleat
13. Shift/throttle control
14. Fire suppression unit manual override
15. Heated seat (where equipped)
16. Wet bar and shower (where equipped)
17. Slide-out refrigerator (under sink, where
equipped)
18. Subwoofer
19. Cooler (under seat)
20. Engine compartment intake
21. Fuel tank filler
22. Stern cleat
23. Engine compartment
24. Automatic fire extinguisher
25. Stern light receptacle (if equipped with tower,
light will be in center aft of tower)
26. Engine compartment exhaust
27. Freshwater flush port (where equipped)
28. Underwater lights (two, where equipped)
29. Transom drain plug (center beneath swim
platform)
30. Anchor Storage
31. Reversible Seat / Step
32. Bow cleat
33. Bow filler cushion (where equipped)
34. Head
35. Hand-held fire extinguisher (inside head)
36. Amp (where equipped)
37. Stereo remote (on dash)
38. Glove box
39. Center drain plug (access plate under carpet)
40. Midship cleat
41. iPod interface (on side panel)
42. Battery switch and circuit breaker panel (on
panel below seat)
43. Batteries (under seat)
44. Convertible observer seat
45. Cooler (under seat)
46. Nav/anchor light
47. Reversible seating (where equipped)
48. Removable ski pylon (where equipped)
49. Fuel tank filler
50. Stern cleat
51. Surf tabs (under swim platform, where equipped)
52. Wake adjustment plate (under swim platform,
where equipped)
53. Swim platform
54. Transom rail with tow eye
SPECIFICATIONS
Length of Boat 26’ 0”
Width Amidship 102”
Boat Weight 6,700 lbs.
Length of Boat w/Platform 28’ 4”
Towing Length 31’ 6”
Towing Width 102”
Fuel Capacity 88 gallons
Maximum Capacity 18 people
Bow: 5 people
Yacht Certified
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
X26

MasterCraft X23 Specifications

General

Beam	102 inches
Seating Capacity	16 People
Surf System	Gen 2 Surf System
Weight	5, 500 pounds
Engine Options	Ilmor 7.4L MPI
Tower	ZFT4
Engine	Ilmor 6.0L MPI
