2016 OWNERS MANUAL / 057
FEATURES
01. Bow cleat
02. Anchor storage (under seat)
03. Horn
04. Ballast tank below floor board
05. Bilge thru-hull outlet
06. Ballast thru-hull vent
07. Navigation light
08. Stereo dash remote (where equipped)
09. Cleat
10. Circuit breaker panel (on kick panel beneath
instrument panel)
11. Instrument panel (details in Video Display
Gauge section)
12. Steering wheel
13. Shift/throttle control
14. Heated seat (where equipped)
15. Fire suppression unit manual override
16. Subwoofer (where equipped)
17. Cooler (under seat)
18. Fuel tank fill
19. Stern cleat
20. Bilge thru-hull vent
21. Engine compartment
22. Automatic fire extinguisher
23. Engine compartment exhaust
24. Transom stereo remote (where equipped)
25. Underwater lights (two, where equipped)
26. Wake adjustment plate (where equipped)
27. Bow filler cushion (where equipped)
28. Amp (where equipped)
29. iPod interface (where equipped)
30. Navigation light
31. Stereo CD Player (inside glove box,
where equipped)
32. Sirius Satellite Radio (where equipped)
33. Glove box
34. Cleat
35. Hand-held fire extinguisher
(inside observer storage)
36. Heated observer seat (where equipped)
37. Center drain plug (under inspection plate)
38. Fuel tank fill
39. Batteries (including ON-OFF switch)
40. Ski pylon
41. Stern cleat
42. Ballast thru-hull vent
43. Engine compartment exhaust
44. Surf tabs (one on each side
below transom)
45. Transom rail with tow eye
46. Transom drain plug
SPECIFICATIONS
Length of Boat 21’ 3”
Width Amidship 98”
Boat Weight 4,550 lbs.
Length of Boat w/Platform 23’ 7”
Towing Length 26’ 5”
Towing Width 102”
Fuel Capacity 50 gallons
Maximum Capacity 14 people
or 1,956 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
X10
