2016 OWNERS MANUAL / 055
FEATURES
01. Bow Cleat
02. Ballast tank (beneath floorboard)
03. Bilge thru-hull outlet
04. Ballast thru-hull vent
05. Nav/anchor light
06. Amp (below)
07. Stereo remote (on dash)
08. Circuit breaker panel (on kick panel beneath
instrument panel)
09. Instrument panel (details in Video Display
Gauge section)
10. Steering wheel
11. Shift/throttle control
12. Heated seat (where equipped)
13. Fire suppression unit manual override
14. Subwoofer
15. Bilge thru-hull vent
16. Engine compartment
17. Auto fire extinguisher
18. Stern cleat
19. Nav/anchor light (if equipped with tower,
the light will be in center aft of tower)
20. Shower wand & switch (where equipped,
inside compartment)
21. Transom stereo remote (where equipped)
22. Underwater lights (two, where equipped)
23. Bow cleat
24. Bow filler cushion (where equipped)
25. Glove box
26. Nav/anchor light
27. Adjustable mirror
28. Walk-thru seat (where equipped)
29. Batteries (under seat)
30. Amp (where equipped)
31. Hand-held fire extinguisher (beneath
observer seat)
32. Heated observer seat (where equipped)
33. Center drain plug (under inspection plate)
34. Cooler (under seat)
35. Batteries ON-OFF switch (under seat)
36. Ski pylon
37. Ballast thru-hull vent
38. Fuel tank filler
39. Stern cleat
40. Engine exhaust
41. Surf tabs (on both sides, where equipped)
42. Transom drain plug
43. Attitude adjustment plate (where equipped)
44. Transom rail with tow eye
SPECIFICATIONS
Length of Boat 20’ 0”
Width Amidship 96”
Boat Weight 4,300 lbs.
Length of Boat w/Platform 22’ 4”
Towing Length 25’ 1”
Towing Width 100”
Fuel Capacity 42 gallons
Maximum Capacity 11 people
or 1,446 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
X2
