OVERVIEW CHARGEMASTER 12/15-2
Settings and Connections
1 RJ12-jack connection, CSI alarm and PC QRS232
2 LED indicator, flashing = BULK / ABSORPTION, continuous=FLOAT
3 Remove jumper for diode compensation
4 Remove jumper for gel/AGM setting
5 Remove jumper for force float
6 Negative DC output common (–)
7 Positive DC output (+)
8 Second positive DC-output (+)
EC declaration of confirmity
Manufacturer Mastervolt
Address Snijdersbergweg 93, 1105 AN Amsterdam , The Netherlands
Herewith declares that product::
43011500 ChargeMaster 12/15-2
Is in conformity with the provision of the EC, EMC directive 2004/108/EC.
The following harmonized standards have been applied:
Emisssion: EN 61000-6-3:2007, Immunity: EN 61000-6-1:2007,
Safety Directive: 2006/95/EC,
Low Voltage Standard: EN 60950:2001 + A11:2004
H.A. Poppelier, Product Manager marine & mobile
2010
