GENERAL INFORMATION
4 August 2009 / Chargemaster1 12/35-3, 12/50-3, 24/20-3 & 24/30-3 / EN
1 GENERAL INFORMATION
1.1 USE OF THIS MANUAL
This manual contains important safety and operating
instructions for the safe and effective operation,
maintenance and possible correction of minor
malfunctions of the Chargemaster1.
It is therefore obligatory that every person who works on or
with the Chargemaster must be completely familiar with
the contents of this manual, and that he/she carefully
follows the instructions and important safety instructions
contained herein. The English version has 28 pages.
Copyright © 2009 Mastervolt. All rights reserved.
Reproduction, transfer, distribution or storage of part or all
of the contents in this document in any form without the
prior written permission of Mastervolt is prohibited.
1.2 VALIDITY OF THIS MANUAL
All of the specifications, provisions and instructions
contained in this manual apply solely to standard versions
of the Chargemaster delivered by Mastervolt.
This manual is valid for the following models:
Part number Model
44010350 ChargeMaster 12/35-3
44010500 ChargeMaster 12/50-3
44020200 ChargeMaster 24/20-3
44020300 ChargeMaster 24/30-3
These models are mentioned as “Chargemaster” further in
this manual.
For other models see the other manuals available on our
website: www.mastervolt.com
1.3 USE OF PICTOGRAMS
Safety instructions and warnings are marked in this
manual by the following pictograms:
WARNING
A WARNING refers to possible injury to the
user or significant material damage to the
charger if the user does not (carefully) follow
the procedures.
CAUTION!
Special data, restrictions and rules with regard
to preventing damage.
A procedure, circumstance, etc which
deserves extra attention.
1.4 IDENTIFICATION LABEL
Figure 1: Identification label
The identification label is located at the right-hand side of
the Chargemaster. (see figure 1) Important technical
information required for service, maintenance & secondary
delivery of parts can be derived from the identification
label.
CAUTION!
Never remove the identification label.
1.5 LIABILITY
Mastervolt can accept no liability for:
• consequential damage due to use of the
Chargemaster;
• possible errors in the manuals and the results thereof.
Serial number
V822A
001
Apparatus version “A”
Part number
Design by
Mastervolt
Made in PRC
Part no : 44020300
Type : ChargeMaster 24/30-3
Input : 120/230V AC 50/60 Hz 8.5A/4.2A
Output : 28.5VDC- 30A
IP 23
Serial no: V822A0001
