TECHNICAL SPECIFICATIONS
Short circuit proctection : yes, reduced output max. 30 Amps
Reverse polarity protection : yes, by internal fuses
Over heat : yes, derating output and shut off by 80°C temperature on heatsink
Storage temperature : -25°C to 80°C
Operating ambient temperature : -20°C to 40°C, derating with 2.5% / °C > 40°C
Humidity : maximum 95%, not condensing
Vibration : according IEC 68-2-6
Cooling : mix of conventional and forced air cooling
Forced cooling : by one variable speed maintenance free DC fan
Environmental protection : IP23
Reliability/life time : • MTBF 30.000 hours
• 1/4 life time period, Uin = 207V AC, Uout = 14,25, Iout = 30 Amps at Tamb 40°C
• 3/4 life time period, Uin = 207V Ac, Uout = 13,25, Iout = 30 Amps at Tamb 25°C
ELECTRO MAGNETIC COMPATBILITY
Electro Magnetic Emission : better than EN 50081-1
(gen. emmission standard, scope; residiential, commercial & light industry)
Electro Magnetic Immunity : better than EN 50082-1
(gen. emmission standard, scope; residiential, commercial & light industry)
Safety : according to IEC 335-2-29, polarity protected by means of a breaker, short break
WHAT TO DO IN CASE OF A DEFECT?
✔ Consult factory in Amsterdam, tel. +31-20-3422100, or your local Repair Center.
COMPLIANCES
• CE:
Is in conformity with the provision of the EC EMC directive 89/336/EEC and amendments 92/31/EEC, 93/68/EEC.
The following harmonized standards have been applied: • Generic emission standard : EN 50081-1:1992
• Generic immunity standard : EN 50082-1:1992
• LLOYDS, DNV, ABS:
MASTERVOLT has constructed this product for rugged circumstances in professional or leisure situations.
This product can be type-approved individually. Price approx. US $ 1500 per certification.
• MANUFACTURED UNDER ISO 9001.
6
48
58
200
111.2
101
83
41
10
10
220
