Mass Combi Pro 12/3000-150, 24/3500-100 – User and Installation Manual
25
8 TECHNICAL DATA
8.1 Specifications
Mass Combi Pro
12/3000-150
24/3500-100
Article number
38013000
38023500
Inverter specifications
Nominal battery voltage
12 V
24 V
Inverter output voltage
230 V (±2%) (adjustable 180 – 200 V)
Frequency
50/60 Hz (±0.005%) configurable
Continuous power
@Tamb=25˚C, cos phi = 1
3000 W
3500 W
Continuous power@Tamb=40˚C, cos phi = 1
3000 W
3500 W
Max. peak load
6000 W
7000 W
Output waveform
True sine wave, Thd < 1 % under standard conditions
Max. efficiency
≥ 90%
≥ 92%
DC input voltage range
9.5 – 16 V
19 – 32 V
Dynamic input window battery
Programmable, current dependent switch-off levels, vary with set battery type
(Gel / AGM settings below)
Switch off voltage low battery@ load ≤ 2%
11.0 V (±2%)
22.0 V (±2%)
Switch off voltage low battery@ load 2-100%
10.5 V - 9.5 V (±2%)
21.0 V - 19.0 V (±2%)
Switch on voltage low battery
12.0 V (±2%)
24.0 V (±2%)
Switch off voltage high battery
16.0 V (±2%)
32.0 V (±2%)
Switch on voltage high battery
14.5 V (±2%)
29.0 V (±2%)
Max. ripple on DC @ full load
< 5% RMS
< 5% RMS
Nominal DC current at full load
300 A
175 A
Recommended batteries
300 – 900 Ah*
200 – 600 Ah*
No load, DC drain
Off mode (hard switched)
0 W
0 W
Inverter off mode (remote)
4 W
4 W
Energy saving mode
7 W
7 W
Normal operation mode
16 W
16 W
Battery charger specifications
Input voltage range
184 – 275 V
184 – 275 V
Max AC input current
12 A
16 A
Max. charge current @Tamb=40˚C
150 A @ 14.25 V adjustable
100 A @ 28.5 V adjustable
Charge characteristic
Mastervolt 3-step+
Battery types
AGM / Gel / MLi / Flooded / Flooded traction / Spiral / NiCad
Battery temperature sense
Input present, sensor included
Voltage sense
Only through MasterShunt, else automatic compensation
Transfer system specifications
AC input 1 (“GEN”) (switched)
Yes, 50 A
Yes, 50 A
AC input 2 (“MAINS”) (switched)
Yes, 30 A
Yes, 30 A
AC Output 1 (“OUT-1”)
Yes, 67 A
Yes, 67 A
AC Output 2 (“OUT-2”) (switched)
Yes, 50 A
Yes, 50 A
AC input fuses
No
No
Transfer speed
Seamless (<1 ms)
Seamless (<1 ms)
Transfer voltage range (adjustable)
184 V-275 V
184 V-275 V
Transfer frequency range (adjust.)
35 – 68 Hz
35 – 68 Hz
Power sharing
Yes
Yes
Generator/Mains support
Yes
Yes
Auto-synchronize with AC input 1 / 2
Yes
Yes
