Mass Combi Pro 12/3000-150, 24/3500-100 – User and Installation Manual
OVERVIEW MASS COMBI PRO
Figure 0-1: Overview of the Mass Combi Pro
1. Display with front switch
6. AC output 1 (“OUT-1”)
11. Sync connector (2x)
2. Main battery negative
7. AC output 2 (“OUT-2”) (switched)
12. Temperature sensor connector
3. Main battery positive
8. DIP switch units (2x8)
13. MasterBus connector (2x)
4. Mains AC input terminal (“MAINS”)
9. Fan (3x)
5. Generator AC input terminal (“GEN”)
10. Ground stud
