November 2000 / Mass Sine 12/1200, 12/2000, 24/1500, 24/2500 & 48/2500/ EN
TECHNICAL DATA
7 TECHNICAL DATA 230V INVERTERS
GENERAL
Function apparatus supplying of AC equipment
Models Mass Sine 12/1200, 24/1500, 12/2000, 24/2500 and 48/2500
Manufacturer Mastervolt, Amsterdam
INPUT 12/1200 12/1200 24/1500 12/2000 24/2500 48/2500
Battery voltage nominal 12 Volt 24 Volt 12 Volt 24 Volt 48 Volt
Switch off voltage low 10 Volt 19 Volt 10 Volt 19 Volt 36 Volt
Switch on voltage low 11 Volt 22 Volt 11 Volt 22 Volt 44 Volt
Switch off voltage high 16 Volt 32 Volt 16 Volt 32 Volt 62 Volt
Switch on voltage high 14 Volt 30 Volt 14 Volt 30 Volt 59 Volt
Maximal ripple 5% RMS
Current (nominal load) 120A 80A 200A 120A 60A
No load (stand by) 50 mA/0.6W 25 mA/0.6W 50 mA/0.6W 25 mA/0.6W 13 mA/0.7W
No load power (low mode) 420mA/5W 210mA/5W 420mA/5W 225mA/5W 110mA/3W
No load (full power) 450mA/6W 225mA/6W 480mA/6W 250mA/6W 140mA/6W
Fuse 120A 80A 240A 160A 100A
DC cables 25 mm
2
25 mm
2
50 mm
2
50 mm
2
35 mm
2
OUTPUT
Output voltage 230 Volt, ± 5%
Output waveform true sine wave, < 5% thd
Frequency 50 Hz, ± 0.1%
Nomimal power Tamb=40°C 1000 Watt 1200 Watt 1800 Watt 2000 Watt 2000 Watt
Half hour power Tamb=25°C 1200 Watt 1500 Watt 2000 Watt 2500 Watt 2500 Watt
Peak power 2400 Watt 2900 Watt 4000 Watt 5000 Watt 5000 Watt
Cos phi all power factors allowed
Efficiency nominal 89% / 92%
CLIMATE
Nominal temperature -20 till 40°C
Cooling partial conventional / forced with temperature regulated fan
Humidity < 95% relative humidity, non condensing
ENCLOSURE
Dimensions (hxwxd) 340 x 261 x 130 mm 420 x 318 x 136 mm
Weight 8 kg 8 kg 14,6 kg 14,6 kg 14,6 kg
Protection degree IP 23
STANDARDS
Emmission EN 50081-1:1992
Immunity EN 50082-1:1997
Safety IEC 950
