INSTALLATION SPECIFICATIONS
November 2004 / MOBILE WHISPER 6/12-6/8/10/12/16 ULTRA / EN 19
50201320 Dry exhaust kit 1” Whisper 6”
no qtt article no description
61 1 ST 50220041 “Exhaust hose 500mm SS male/female 1”
62 1 ST 50220042 Insul. blanket 35x60 exhaust hose 1 1/2
63 1 ST 50230520 “Absorbtion muffler steel 1”
64 1 ST 50230521 “Ressonance muffler steel 1”
65 1 ST 50230522 “Insulation blanket R-muffler 1”
66 2 ST 50221401 “Pipe nipple 1”x300mm galvanised”
67 2 ST 50221421 “Parallel male coupling 1” galvanised”
68 2 ST 50221411 “Straigt coupling f/f 1”galvanised”
69 3 ST 50221661 U-clamp 42mm M10
70 3 ST 50221664 Bracket U-clamp 25cm M10/48mm passivated
71 6 ST 50211406 Washer SP M10
72 6 ST 50211447 Washer spring SP M10
73 6 ST 50211466 Nut hexogonal SP M10
75 1 ST 50221471 “Elbow 90 degr m/f gavalvanised 1””
50201875 Dry exhaust kit 1,5” Whisper 12/6-8-10-12-16 Ultra
no qtt article no description
61 1 ST 50220043 “Exh.hose SS 500mm fem./male 11/2”
62 1 ST 50220042 Insul. blanket 35x60 exhaust hose 1 1/2
63 1 ST 50230523 “Absorbtion muffler steel 11/2”
64 1 ST 50230524 “Ressonance muffler steel 11/2”
65 1 ST 50230525 “Insul. blanket 80x75 muffler SDHC 11/2”
66 2 ST 50221403 “Pipe nipple 11/2”x300mm galvanised”
67 2 ST 50221423 “Parallel male coupling 11/2” galvanised”
68 2 ST 50221413 “Straigt coupling f/f 11/2”galvanised”
69 3 ST 50221663 U-clamp 48 mm M10
70 3 ST 50221664 Bracket U-clamp 25cm M10/48mm passivated
71 6 ST 50211406 Washer SP M10
72 6 ST 50211447 Washer spring SP M10
73 6 ST 50211466 Nut hexogonal SP M10
75 1 ST 50221473 “Elbow 90 degr m/f gavalvanised 11/2”
50201878 Radiator cooling kit alternator 230VAC
Whisper 6,12/6,8,10,12 ULTRA
no qtt article no description
31 1 ST 50230304 Radiator cooler AP 300/2 E 230VAC
32 2 ST 50221103 “Straight reducer m/f 1”-3/4”
33 1 ST 50221063 “Male nipple 3/4”
34 1 ST 50221043 “TEE fittings 3/4”
35 3 ST 50221004 Male hose connection 3/4x20
38 1 ST 50212405 Temperature switch 35-45 degr
39 4 ST 50201121 Vibration mounting 30x25
40 4 ST 50211152 Bolt hexagonal ZP M8x16
41 8 ST 50211465 Nut hexogonal SP M8
42 8 ST 50211405 Washer SP M8
43 8 ST 50211445 Washer spring SP M8
44 8 M 50220011 “Hose vacum SAE100R4 (3/4”) 19x31,5mm
45 6 ST 50221502 Hose clamp stainless19-29
46 8 ST 50221599 Hose support 35x15 mm galvanised
47 1 ST 50230529 Bracket expansion tank for 50230531
47 1 ST 50230531 Expansion tank 20 mm
47 1 ST 50230532 Cap tank 0502 30531
50201872 Radiator cooling kit alternator 12VDC Whisper 6/6 ULTRA
50201868 Radiator cooling kit alternator 24VDC Whisper 6/6 ULTRA
