INSTALLATION SPECIFICATIONS
20 EN / MOBILE WHISPER 6/12-6/8/10/12/16 ULTRA / November 2004
50201888 Radiator cooling kit alternator 230VAC Whisper 16
no qtt article no
31 1 ST 50230307 Radiator AP 430 230VAC
32 1 ST 50221103 “Straight reducer m/f 1””-3/4”””
33 1 ST 50221064 “Male nipple 1”””
34 1 ST 50221044 “TEE fitting 1”””
35 2 ST 50221010 Male hose connection 1x25
35 1 ST 50221004 Male hose connection 3/4x20
38 1 ST 50212405 Temperature switch 35-45 degr
39 4 ST 50201121 Vibration mounting 30x25
40 4 ST 50211152 Bolt hexagonal ZP M8x16
41 4 ST 50211465 Nut hexogonal SP M8
42 4 ST 50211405 Washer SP M8
43 8 ST 50211445 Washer spring SP M8
44 6 M 50220012 “Cooling water hose smooth (1””) 25x34 mm”
44 1.5 M 50220011 “Cooling water hose smooth (3/4””)18x27 mm”
45 2 ST 50221502 Hose clamp stainless19-29
45 4 ST 50221503 Hose clamp stainless 26-38
47 8 ST 50221599 Hose support stainless 35x12 mm
47 1 ST 50230529 Bracket expansion tank for 50230531
47 1 ST 50230532 Cap tank 0502 30531
47 1 ST 50230531 Expansion tank 20 mm
50201879 Radiator cooling kit engine 230VAC Whisper 6/6 Ultra
no qtt article no description
11ST50230304 Radiator cooler AP 300/2 E 230VAC
22ST50221502 Hose clamp stainless19-29
31ST50221064 “Male nipple 1”
41ST50221044 “TEE fitting 1”
52ST50221010 Male hose connection 1x25
61ST50221103 “Straight reducer m/f 1”-3/4”
71ST50221004 Male hose connection 3/4x20
81ST50212409 Temperature switch 87-82 degr
94ST50201121 Vibration mounting 30x25
10 4 ST 50211152 Bolt hexagonal ZP M8x16
11 4ST50211465 Nut hexogonal SP M8
12 8 ST 50211405 Washer SP M8
13 8 ST 50211445 Washer spring SP M8
14 6 M 50220012 “Hose vacum SAE100R4 (1”) 25,4x38mm”
15 4 ST 50221503 Hose clamp stainless 26-38
16 8 ST 50221599 Hose support stainless 35x12 mm
17 1 ST 50230529 Bracket expansion tank for 50230531
17 1 ST 50230531 Expansion tank 20 mm
17 1 ST 50230532 Cap tank 0502 30531
18 1.5 M 50220011 “Hose vacum SAE100R4 (3/4”) 19x31,5mm
21 1 ST 50221532 Hose clamp stainless mini 9-11
50201871 Radiator cooling kit engine 12VDC Whisper 6/6 Ultra
50201880 Radiator cooling kit engine 24VDC Whisper 6/6 Ultra
