INSTALLATION
10 Copyright © 2009 Mastervolt / October 2009 / WHISPER 3.5 / EN
Figure 10: Super silent exhaust system
Figure 11: Only after the exhaust / water separator the exhaust hose may have a length up to 7,5m
MAX. 10CM (4")
MIN. 60CM (24")
MAX. 120CM (48")
MIN. 3CM (1,2")
1
2
3
4
Ø 40 mm
Ø 40 mm
Ø 40 mm
1 Water level 3 Seacock
2 Water/exhaust separator 4 Waterlock
A
B
Max. length A - B = 2.5 m. (8 ft)
Ø 40 mm
Ø 40 mm
Ø 40 mm
Ø 40 mm
