DIAGRAMS & DRAWINGS
26 Copyright © 2009 Mastervolt / October 2009 / WHISPER 3.5 / EN
3.2 WIRING NAMES AND COLOURS
Wire number Wire name Colour Cross section
1 Battery + White 2.5 mm²
2 Battery – White 2.5 mm²
3 Glow + White 2.5 mm²
4 Start solenoid + White 2.5 mm²
5* Stop solenoid – White 2.5 mm²
6 Stop solenoid + White 1.5 mm²
7 Fuel valve + White 1.5 mm²
8* Fuel valve – White 1.5 mm²
9 Fuel pump + Brown 1.5 mm²
10 Fuel pump – Black 1.5 mm²
11 Charger a White 1 mm²
12 Charger b White 1 mm²
13 Safety switch + White 1 mm²
14 Safety switch – White 1 mm²
15* Battery + White 2.5 mm²
16* Battery + White 2.5 mm²
17* Start relay + White 1 mm²
18* Glow relay + White 1 mm²
19* Battery – White 1 mm²
22 Oil pressure + White 1 mm²
23* Oil pressure – White 1 mm²
24 Exhaust temp. + White 1 mm²
25 Exhaust temp. – White 1 mm²
26 Engine temp. + White 1 mm²
27 Engine temp. – White 1 mm²
30 Iac1-L White 1 mm²
31 Iac1-N White 1 mm²
40 Uac1-L White 1 mm²
41 Uac1-N White 1 mm²
49* Ground relay + White 1 mm²
Battery + Red 16 mm²
Battery – Black 16 mm²
Earth wire Green/yellow 6 mm²
* Ungrounded versions only (part nr. 51200506)
