Matrix Audio element X - Rear Panel; Display Screen; Dispaly in Main Interface Area; Volume Control

Parts & name
02
2.3 Display screen 2.2 Rear panel
1. Status for NAS devices
2. Status for USB storage devices
3. Status for MicroSD card
4. Status for Wi-Fi and ethernet
connection
5. Input channel
6. Sampling rate
7. Assistant information
8. Volume bar
9. Output mode
1. Current volume dB level
BAL
dB
-30.0
12 12 11 10 8
1. XLR right chanel output
2. RCA right chanel output
3. RCA left chanel output
4. XLR left chanel output
5. Coaxial input
6. Wi-Fi antenna jack
7. MicroSD card slot
8. USB HOST port
9. Wired netword port
10. USB Audio port
11. IIS LVDS input
12. Optical input
13. Power input
2.3.1 Dispaly in main interface area
2.3.2 Volume control
9
13421 5 5 6
6
7 83
L
R
XLRXLR
RCA RCA
2. Volume bar 3. Output mode
1 2 3
PCM 44.1
Optical 1
Filter 5 k
5 6 7 984321
UNBAL
Users Manual
