Connection
05
Connection for front-end devices including S/PDIF output signal through coaxial and
optical port;
Connection for digital interface products of Matrix Audio through IIS prot.
3.2 Connect to input source
There are two headphone hybrid chassis jacks and one XLR balanced headphone jack.
You can use three ways to connect to headphone:
It is advisable to connect with high-impedance headphone for the best sound effect. If
it is connected to a low-impedance and high sensitivity headphone, in order to
decrease the noise, it is advisable to set the gain of headphone AMP at 'LOW' and
consider if an impedance cable is needed.
3.3 Connect to headphone
6.35mm
XLR.3
XLR.3
XLR.4
6.35mm
TV CD Player
Game Console
Computer
L
R
XLRXLR
RCA RCA
