Matrix COSEC ARGO User Manual

24
Figure 20 : Tenant ID (COSEC VYOM)
Figure 19 : Tap Switch to VYOM
In case of COSEC VYOM
Figure 18 : Set Server Address
(COSEC CENTRA)
Figure 17 : Set IP Address
(Static/ Dynamic)
Configuring the Settings from ARGO FACE
Assigning IP/ Server Address to Device (For first time user only)
23
GND
• Connect the Overswing diode in reverse biased condition
parallel to the EM Lock for better lifetime contact and to
protect the device from inductive kickback.
EM
Lock
Reverse biased
Diode
Anode
-
+
Power
Cathode
Diode Connection for Back EMF Protection
Relay Relay
Pin 1 Pin 2
