Built In Cameras
•
For providing efficient Face Recognition, two Cameras are used in
COSEC ARGO.
•
These Cameras are 2MP with Focal length of 2.8mm. The Cameras
detect liveness and capture user images. The captured image is used
to identify user for Time and Attendance Management.
What your Package Contains
•
The Flush Mounting plate is available in the package. This plate will be
required for Flush Mounting of COSEC ARGO. For details see
Installation Instructions for Flush Mounting.
Wall Mounting:
Select a location. It must be a flat surface such as wall,
close to the access point (door).
Flush Mounting
: Select a wooden door or a location where the duct can
be made. The rectangular duct has to be made in the wooden door in
which Flush Mounting plate will be installed.
For
Concealed wiring
in Wall Mounting/Flush Mounting, first draw out
1)
COSEC ARGO Unit
2)
Flush Mounting Plate
3)
Wall Mounting Plate
4) Four Screws M5/25
5) Four Screw Grips
6)
Overswing Diode
7)
Power Adapter 12VDC,2A
8) Power Supply Cable (with DC Jack)
9)
EM Lock Cable
10)
External Reader Cable
11)
Flush Mounting Template
sufficient length of the cables from the hole of the mounting plate.
For
Non-concealed wiring
in Wall Mounting; the knock -out area has to
be removed from outside by pressing on the bottom duct as shown
in
Figure 2
.
Preparation for Installation
Before Wall Mounting and Flush Mounting of COSEC ARGO follow below
instructions.
•
Remove the mounting screw from mounting screw hole at the bottom
of device as shown in
Figure 2
. The screw will be required to fix the
device after Wall Mounting or Flush Mounting.
•
Slide the back plate downwards to unlock the device from the
mounting hook and then remove it by pulling it outwards. This back
plate servers as the Wall Mounting plate. For details see Installation
Instructions for Wall Mounting.
The connection of EM Lock must be done using the diode for Back
EMF protection.
7
8
