Matrix COSEC ARGO - Technical Specification

34
33
Technical Specification
Event Buffer
5,00,000
Input Power
12V DC @2A and PoE
Credential
Support
Face, PIN, Card, BLE
Reader Power
Output
Max 12V DC @0.250A
Reader Interface
Type
RS 232 and Wiegand
Door Lock
Relay
Max 30V DC @2A
Door Lock
Power
POE Power: 12VDC@0.250A
Adapter Power: 12VDC@0.5A
Built In PoE
PoE (IEEE 802.3 af)
Display
3.5 inch Capacitive IPS touch screen
with Gorilla glass 3.0;
Resolution: 480x320 pixels (HVGA)
User Capacity
50,000
Communication
Port
Mobile Broadband, Ethernet and WiFi
Technical Specification
Built In WiFi
Yes (IEEE 802.11 b/g/n)
Built In
Bluetooth
Yes
Built In USB
Yes
Operating
Temperature
0 °C to +50 °C
Dimensions
(H x W x D)
186mm x 74mm x 50mm (Wall Mount)
186mm x 74mm x 16mm (Flush Mount)
Weight
0.550 Kg (Product Only)
1.2 Kg (Product with Accessories)
RF Option(Card)
ARGO FACEE
ARGO FACEM
ARGO FACEI
EM Prox
MIFARE
R
/ Desfire / NFC
HID I Class,
HID Prox, EM Prox
and
Desfire/ NFC/
MIFARE
R
