Matrix ETERNITY NE Quick Start 14
Ethernet WAN
If ETERNITY NENX is connected to a Public Network,
• Connect the Extended IP Phone, or any Open IP Phone to the LAN Switch.
• Register any SIP device (Extended IP Phone/ Softphone client or Open IP Phone) on the public network
as SIP Extension.
When you register any SIP device, other than the Extended IP Phone, on the public network as SIP
Extension, you must configure the Registrar Server Address of ETERNITY NENX, the Registrar Server
Port, the SIP ID, Authentication ID and Password in the SIP Device.
Modem/
Router
IP
IP
GSM/UMTS/
LTE
LAN Switch/Hub
Ethernet
WAN
SLT Extensions
SIP Extensions
SIP Extension
CO
