11
S
TEP 2
| U
SER FRAME INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
2
M10 X 30L
SHC
4
8
User Frame
1
9
M10 Saddle W
asher
4
ASSEMBL
Y
P
AR
T 1: USER FRAME ASSEMBL
Y
8
9
2
View A
•
Install the user frame hardware as shown, being sure to orient the saddle washer as shown in
View A.
•
Ensurethattheframeislevelandthatalloorpadscontacttheoorequally
,
•
T
orqueallM10FrameHardwareonpages10&1
1to:77N-m/57ft-lbs.
10
12
Table of Contents
Table of Contents
2
Safety, General Care & Maintenence
3
Getting Started (Product Specifications)
5
Assembly Information
6
Markings
7
Parts List
8
Part 1 Weight Stack & User Frame Assembly
10
User Frame
11
M10 Saddle Washer
11
Part 2 Seat Assembly
12
Medium Pivot Cap
12
Seat Link
12
Axle
12
Spring
12
Seat
12
Axle
13
Part 3 Arm Assembly
14
Right Lower Arm Assembly
14
M5 Flat Washer
15
Cap
15
Axle Locking Sleeve
15
Wave (Spring) Washer
15
Cam
16
Spacer
16
ROM Adjustment Cable
18
Cable Retainer
18
Part 4 Pad Assembly
21
Part 5 Plastics Assembly
24
