13
S
TEP 2
| SEA
T ASSEMBL
Y INS
TR
UCTIO
NS & NO
TES
ID
DESCRIPTION
QUANITY
10
M8 X 25L
SHC
6
11
Medium Pivot Cap
6
12
Seat Link
3
13
Axle
2
14
Spring
1
ASSEMBL
Y
P
AR
T 2: SEA
T ASSEMBL
Y
T
ightento39N-m/29ft-lbs.
Rotate seat to
engage pull pin
Assemble
upper axles,
links and
pivot caps
12
14
Table of Contents
