16
STEP 3 | LEFT ARM ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
16 Axle 1
23 CAM 1
24 Spacer 1
25 LeftLowerArmAssembly(w/pullpin) 1
ASSEMBLY
PART 3: ARM ASSEMBLY
25
23
24
16
Squareendofaxlemust
be located as shown
