25
S
TEP 2
| T
OP CAP AS
SEMBL
Y INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
47
M8 X 60L
SHC
4
48
T
op Cap
1
ASSEMBL
Y
P
AR
T 5: PL
ASTICS AS
SEMBL
Y
Install the top cap and connect rep
counter plug as shown.
T
orqueto17N-m/147in-lbs.
Position top cap so Rep Counter faces
the user
.
48
47
IMPORT
ANT NO
TICE
PLEASE NOTE:
Be sure to remove the insulating
sheet when installing the
Rep Counter
.
24
26
