12
PART 1: USER FRAME ASSEMBLY
STEP 3 | USER FRAME INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
4 M10 Saddle Washer 2
6 M10 X 30L SHC 2
ASSEMBLY
6
4
Tip frame as shown to access hardware.
DO NOT FULLY TIGHTEN
