22
ASSEMBLY
STEP 5 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES
PART 3: ARM ASSEMBLY
34
35
36
Torque to: 39 N-m/29 ft-lbs.
ID DESCRIPTION QUANITY
34 Counter Weight 2
35 M8 Flat Washer 4
36 M8 X 15L SHC 4
