Matrix MAGNUM SERIES - Assembly Instructions by Model; MG-A526 Assembly Steps

6
A
A
A
B
C
MG-A526
STORAGE AREA
FREE AREA
0.6 m (2 ft)
wide path
1.86 m
(73.36ʺ)
0.63 m
(24.6ʺ)
1
Step 1 Hardware
Description Qty
A Bolt (M10x25L) 6
Step 2 Hardware
Description Qty
A Bolt (M10x25L) 6
2
Step 3 Hardware
Description Qty
A
B
C
Bolt (M10x25L)
Flat Washer (M10)
Nut (M10)
16
16
16
3
Repeat for
each tier
ENGLISH
